Barrel material：Brass C3604/C6801

Plunger material：Brass C3604/C6801

Spring material：SUS304

Housing material: PA9T UL94v-0,black

Plunger plating spec：15u“ min. Au over 50-100u" Ni

Barrel plating spec：4u“ min. Au over 50-100u" Ni

Rating current：2A AC/DC

Rating voltage： DC36V

Contact resistance：30 mohm max.

Durability： 10000-100000 cycles

Salt spray：48 hours min.

RoHS and REACH compliant

Withstanding high temperature: 260℃/10s
