Pin material：Brass C6801

Housing material: PA9T UL94v-0,black

Plating spec：20u“ min. Au over 50-100u" Ni

Rating current：5A AC/DC

Rating voltage： DC12V

Contact resistance：30 mohm max.

Durability： 10000-100000 cycles

Salt spray：48 hours min.

RoHS and REACH compliant

Withstanding high temperature: 260℃/10s
