Material：Brass C6801

Plating spec：3u“ min. Au over 50-120u" Ni

Rating current：1-2A AC/DC

Rating voltage： DC24V

Contact resistance：30 mohm max.

Durability： 10000-100000 cycles

Salt spray：48 hours min.

RoHS and REACH compliant

Withstanding high temperature: 260℃/10s
