Barrel material：Brass C3604/Brass C6801/Becu

Plunger material：Brass C3604/Brass C6801/Becu

Spring material：SUS304/SWP/Becu

Plunger plating spec：5u“ min. Au over 100-150u" Ni

Barrel plating spec：5u“ min. Au over 100-150u" Ni

Rating current：1A

Rating voltage： DC5V

Contact resistance：30 mohm max.

Durability： 10000-100000 cycles

Salt spray：48 hours min.

RoHS and REACH compliant

Withstanding high temperature: 260℃/10s
