Barrel material：Brass C3604/Brass C6801/Becu

Plunger material：Brass C3604/Brass C6801/Becu

Spring material：SUS304/SWP/Becu

Plunger plating spec：32u“ min. Au over 100-150u" Ni

Barrel plating spec：10u“ min. Au over 100-150u" Ni

Spring plating spec：4u“ min. Au over 50-100u" Ni

Rating current：2A  continuous, 3A peak

Rating voltage： DC24V

Contact resistance：30 mohm max.

Durability： 10000-100000 cycles

Salt spray：72 hours min.

RoHS and REACH compliant

Withstanding high temperature: 260℃/10s
